ACU-RITE 3500i 355
11.1 G-Code Program Editing
Edit Features menu
When editing a program, the following buttons are available in the Edit
Features menu:
Button Function
Insert Block inserts a blank line for a program block
at the cursor. This differs from the Insert key on the
Edit Menu.
Mark is used to mark and unmark program blocks.
Copy will copy program block(s) or part of a block.
Paste will paste copied or cut block(s) into another
section of the program.
Cut will remove program block(s) or part of a block,
and place them onto the clipboard.
Undo will undo the previous step(s) sequentially.
Redo will redo the previous step(s) sequentially.
Quit exits the program without saving any changes.
Previous Menu returns to the previous menu.
