10.1 CAM Programming
Modifying Toolbar
In the following table is a brief description of the Modifying Tools
located in the Modifying Toolbar. These buttons provide the ability to
Modify existing geometry. They are described in more detail later in
this chapter. See "Modifying Tools" on page 322.
Modifying Tools Buttons:
Button Function
Select Corner Radius to add a corner radius.
Select Chamfer to add a chamfer.
Select Trim to trim geometry.
Select Delete to delete geometry.
Select Properties to display geometry properties.
