9.1 Running a program
Starting a program
With a program selected and in Program Run Mode, touch the Auto
button to put the 3500i in auto mode.
Select the starting block in the program if necessary.
Touch the START button to execute the program, placing the CNC in
motion.
Pause, or Stop a running program
Press the STOP key to stop, or pause the program and machine
motion.
Press the START key to resume the program, placing the CNC in
motion, or:
Touch the Manual button to cancel a program that is stopped.
Clearing a Messages
Go to System Maintenance, and select Messages to clear or review
messages that have been displayed.
Touch the message bar on the screen to clear a Warning message.
This removes it from the screen, but a copy is saved in the Messages
screen until it is deleted.
To delete error messages, go to System Maintenance, and select
Messages. Highlight a message and touch the Delete button.
All error messages can be deleted in one step by touching the
Delete All button.
One or more error messages may be generated from a program
error.
Re-load the program after it has been corrected, and restart at the
appropriate block.
A program can be started at the beginning, or at a block
location within the program.
Only Error messages will stop a program. Warning
messages can be cleared, and the program will continue.
