ACU-RITE 3500i 187
7. 2 C a n n e d C y c l e s
G-code format: G210
Field Code Description
FinStock S Amount of stock left by the roughing
passes for a finish pass. This amount
applies to the sides and bottom unless R
(SideStock) is defined; then, S (FinStock)
only applies to the bottom. Default is no
stock left.
SideStock R Amount of stock left by the roughing
passes for a finish pass on the sides only.
This amount overrides the value in S
(FinStock). A value of zero can force stock
to be left only on the bottom. Default is
equal to S (FinStock).
ZFeed I The feedrate at which the tool will "ramp"
into the slot in all three axes. Default is last
programmed feedrate.
Rough
Feed
J Feedrate used during roughing passes.
Default is last programmed feedrate.
FinFeed K Feedrate used during finish passes. Default
is last programmed feedrate.
RetractHgt P Z-axis absolute start and finish height (must
be equal to or above "H"), used as a safety/
clearance Z position before making X/Y
moves. Executed in rapid at start and end of
cycle. Defaults to current Z position at
beginning of cycle.
Coarse
Tool
T Number of tool used for previous roughing
cycle.
SkipRough E Yes = Roughing pass is skipped, only finish
pass is performed.
No = Roughing pass is performed. (Default)
SkipFinish F Yes = Finish pass is skipped, only rough
pass is performed.
No = Finish pass is performed. (Default)
Direction Q Select Cw or Ccw.
