ACU-RITE 3500i 159
7. 2 C a n n e d C y c l e s
When you enter a value, the CNC executes the number of passes
required to get from the H (StartHgt) to the Z (ZDepth), cutting the
B (DepthCut) on each pass.
When you do not enter a J (RoughFeed) or K (FinFeed), the CNC
executes feed moves at the current feedrate. J (RoughFeed)
controls the feedrate of the roughing cycle. K (FinFeed) controls the
feedrate of the finishing cycle.
G-code format: G175
Field Code Description
FinFeed K XY axes finish feedrate. Defaults to last
programmed feedrate.
FinStock S Finish-stock amount per side (including
bottom). If not programmed, no finish stock
is left.
Type Q Specifies the type of entry move;
1=Line Tangent, 2=Line Perpendicular,
3=Arc Tangent, 4=Line Arc Tangent.
Length M Length of entry move.
Radius R Radius of entry arc.
Angle C Angle of entry arc.
