106 6 Conversational Editing
6.1 Conversational Programming
Milling Feature Buttons
When the Milling Button is selected, the bottom menu bar changes
to provide the following features to add, or edit the milling
requirements of the program.
Button Function
RPM opens the Spindle RPM dialogue so that the
spindle RPM speed can be set.
Entry Move opens the Entry move dialogue to input
data for how the cutting tool will enter into the part.
Rapid opens the Rapid move dialogue to enter data
to the EndPoint destination.
Line opens the Line dialogue to enter data to mill a
line to an EndPoint destination.
Arc opens the Arc dialogue to enter data to mill an
arc to an EndPoint destination.
Exit Move opens the Exit move dialogue to input
data for how the cutting tool will exit the part.
Tool opens the Tool dialogue to enter the Tool
number and dimensions to be used.
Repeat opens the Repeat dialogue to select a set of
blocks in the program.
Sub Programs opens the menu list to choose what
type of sub program is to be used, e.g. Sub, EndSub.
Closes the bottom bar menu, and returns to the
main bottom bar menu.
