User guide
Table Of Contents
- Special Notes
- Register Your Product
- Typical Product Parameters
- Label Location
- Section 1— General Guidelines
- Section 2— Operation
- Installing the Mattress Replacement System
- Installing the Side Rails
- Installing the Power Unit
- Connecting the Hose
- Connecting the Power Cord
- Using the Front Panel
- Power Button
- Turn Button (MA90Z Power Unit)
- Turn Time Button (MA90Z Power Unit)
- Turn Angle Button (MA90Z Power Unit)
- Rotation Button (MA95Z Power Unit)
- Select Button (MA95Z Power Unit)
- Hold Button (MA95Z Power Unit)
- Firm/Soft Buttons
- Automatic Wireless Fowler
- Mode Button (MA90Z Power Unit)
- Max Inflate Button (MA95Z Power Unit)
- Lock/Alarm Silence Button
- Power Fail LED
- Low Pressure LED
- Displaying the Total Run Time (MA95Z Power Unit)
- Powering Up the System
- Placing the Patient on the Mattress
- Transferring Patient From/To a Gurney
- Transferring Patient From/To a Wheelchair
- Preparing for CPR Procedure
- Section 3— Maintenance and Troubleshooting
- LIMITED WARRANTY
SECTION 2—OPERATION
MA90 and MA95 Series Mattresses 12 Part No 1148139
Connecting the Hose
CAUTION
Ensure that the hose connecting the control unit to the mattress is routed such that
it cannot be stepped on, kinked, squeezed or otherwise damaged.
NOTE:Forthisprocedure,refertoFIGURE 2.3.
1. Locatethehoseatthefootendofthemattress.
2. Locatethecontrolunitconnectorontherightsideofthecontrolunit.
3. Performoneofthefollowing:
• MA90ZPowerUnit‐Performthefollowingsteps(Detail“A”):
i. Squeezeandholdthetabsonthehose
connectors.
ii. Insertthehoseconnectorsintothecontrolunitconnector.
iii. Pushthehoseconnectorsontothecontrolconnectoruntilanaudibleclickis
heard.
NOTE:Theaudibleclickindicatesthatthehoseconnector(s)areproperlyengagedwiththe
controlconnectors.
• MA95ZPowerUnit‐Performthefollowingsteps(Detail“B”):
i. Liftandholdtheconnectorcoverup.
ii. Pushthehoseconnectorontothecontrolconnector.
iii. Ensurethehoseconnectorisflushwiththecontrolunitconnector.
