A packet can match more than one rule. This means that:
The first class rule has precedence over all other class rules (scanning is s
stopped once the first rule is reached).
The first traffic-priority (classless) rule has precedence over all other traffic s
priority rules.
There is no prevention of a traffic-priority rule conflicting with a class rule. In s
this case, the priority and DSCP setting of the class rule (if given) will
take precedence.
Click 1. Quality of Service in the Advanced screen, then click 802.1p Settings.
The “802.1p Settings” screen appears.
The eight 802.1p values are pre-populated with the three priority levels: 2. Low,
Medium, and High. These levels can be changed for each of the eight values
in their respective drop-down lists.
Click 3. Apply to save the settings.
A.2f Class Statistics
The FiOS Router provides accurate, real-time information on the traffic moving
through the defined device classes. For example, the amount of packets sent,
dropped, or delayed are just a few of the parameters monitored per each
shaping class.
