USER INSTALLATION MANUAL Of Wireless LAN 802.
User Manual of Wireless LAN 802.11a/g Dual Band PCI Adapter Contents: 802.
User Manual of Wireless LAN 802.11a/g Dual Band PCI Adapter Device Description The 802PAG is a Wireless PCI adapter to support IEEE 802.11b/g and/or 802.11a standard. This adapter can be configured to support either 802.11b/g only or 802.11abg standard. System Requirements Desktop PC containing: - 32-bit PCI Bus slot 32 MB memory or greater 300 MHz processor or higher Microsoft Windows 2000 / Windows Me / Windows 98 second Edition / Windows XP / Windows NT 4.
User Manual of Wireless LAN 802.11a/g Dual Band PCI Adapter Windows 2000 Driver Installation (First-Time Installation) This section describes the 1st time installation for the driver for Windows 2000. Insert 802PAG into a PCI Bus slot and follow these steps to install the NDIS driver: 1. Wait for the Found New Hardware Wizard dialog box to display. 2. Click Next to continue. 3. Choose “search for a suitable driver for my device (recommended).” 4. Click Next. 5. Insert the release CD into the CD-ROM drive.
User Manual of Wireless LAN 802.11a/g Dual Band PCI Adapter 5 ACU Installation and Driver Update There is an InstallShield utility to upgrade the NDIS driver, if a previous release is installed, and to install the Atheros Client Utility (ACU). When an NDIS driver has been previously installed, insert the 802PAG into a PCI Bus. Follow these steps to update the NDIS driver: 1. 2. 3. 4. Open the InstallShield Wizard (setup.exe). Click Next to continue. Click ‘Yes’ to accept the License Agreement.
User Manual of Wireless LAN 802.11a/g Dual Band PCI Adapter Driver and ACU uninstallation This section provides information about uninstallation procedures. To uninstall the ACU and the NDIS driver: Use the InstallShield Updater to uninstall the NDIS driver and ACU application and remove them from the Device Manager. 1. 2. 3. 4. Open the InstallShield Wizard (setup.exe). Click Next to continue. Click ‘Yes’ to accept the License Agreement.
User Manual of Wireless LAN 802.11a/g Dual Band PCI Adapter 7 LED Indicator There are two LED indicators.
User Manual of Wireless LAN 802.11a/g Dual Band PCI Adapter 8 Regulatory Compliance Information Radio Frequency Interference Requirements This device is restricted to indoor use due to its operations in the 5.15 to 5.25 GHz frequency range. FCC requires this product to be used indoors for the frequency range 5.15 to 5.25 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite systems. High power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.
User Manual of Wireless LAN 802.11a/g Dual Band PCI Adapter 9 FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
