Bullet Camera Series Hardware Manual E35, E36, E37 Ver.
Hardware Manual Table of Contents Precautions 4 Safety Instructions ........................................................................... 6 Introduction 7 List of Models.................................................................................... 7 Package Contents............................................................................. 8 Physical Description ........................................................................ 9 Mounting Options ...................................
Hardware Manual Appendix 36 How to Make an Ethernet Cable .................................................... 36 3 www.acti.
Hardware Manual Precautions Read these instructions You should read all the safety and operating instructions before using this product. Heed all warnings You must adhere to all the warnings on the product and in the instruction manual. Failure to follow the safety instruction given may directly endanger people, cause damage to the system or to other equipment.
Hardware Manual Federal Communications Commission Statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Hardware Manual Safety Instructions Don’t open the housing of the product Cleaning Disconnect this video product from the power supply before cleaning. Attachments Do not use attachments not recommended by the video product manufacturer as they may cause hazards. Water and Moisture Do not use this video product near water, for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool and the like.
Hardware Manual Introduction List of Models This hardware manual contains the following models: E35 3MP Bullet with D/N, Adaptive IR, Superior WDR, Fixed lens E36 1.3MP Bullet with D/N, Adaptive IR, Basic WDR, SLLS, Fixed lens E37 10MP Bullet with D/N, IR, Basic WDR, Fixed lens 7 www.acti.
Hardware Manual Package Contents Camera Sunshield Bracket Bracket Plate Conduit Gland Quick Installation Guide 8 Sunshield Screw Kit Lens Focus Tuner (not available in E37) Warranty www.acti.
Hardware Manual Physical Description NOTE: The shape of the Ethernet port on the actual camera may vary. 1) Memory Card Slot Insert a memory card (not included) into this slot for local recording purposes. See How to Install / Remove the Memory Card on page 26 for more information. NOTE: Supports microSDHC and microSDXC cards. 2) Reset Button Use the Reset Button to reset the camera to its factory default settings.
Hardware Manual Mounting Options In areas with fierce weather conditions, the light bundled bracket can be replaced by a heavy duty outdoor bracket combined with additional mounting accessories. Below are the optional mounting accessories that you can use with the camera. Mount Types Accessories Corner Mount Suitable when mounting the camera on a corner wall. PMAX-1103 PMAX-0402 + Pole Mount Suitable when mounting the camera on a pole.
Hardware Manual Installation Procedures Using the Bundled Bracket Step 1: Install the Bundled Bracket 1. Mark the location of the three (3) screw holes using the bracket plate included in the package. NOTE: Depending on the surface where you will install the camera, it may be necessary to drill the holes and use the supplied screw tox. 2. Attach the plate to the surface using the three (3) supplied screws. 3. Attach the bracket to the plate. 11 www.acti.
Hardware Manual Step 2: Attach the Sunshield The use of sunshield is optional if the camera will be installed indoors. However, if the camera will be installed outdoors, attach the sunshield to protect the lens from all types of weather and lighting conditions. 1. Loosely secure the supplied screws and washers to attach the sunshield. 2. Slide to adjust the sunshield to cover the lens as far as possible but out of the camera’s live view. 3. Tighten the screws to fix the position of the sunshield.
Hardware Manual Step 3: Install the Camera Before installing the camera, determine the most suitable method to waterproof the cable connection (see Step 4: Waterproof and Connect the Cable on page 14). Some methods may require the cable to be waterproof first before installing the camera to its bracket. 1. Depending on how you want to install the camera, attach the camera to the bracket through one of the two (2) holes below: 2.
Hardware Manual Step 4: Waterproof and Connect the Cable If the camera will be installed indoors, simply connect the network side cable to the camera Ethernet port. No need to waterproof the cable connection. However, if the camera will be installed outdoors, check the type of Ethernet port and follow the applicable procedures to waterproof the cable connection.
Hardware Manual Using the Waterproof Tape Connect an Ethernet cable from the network side to the Ethernet port of the camera to complete the installation. Camera Side Network Side NOTES on using Ethernet cables: For outdoor installations, it is recommended to use exterior-grade Ethernet cables (CAT5/CAT5e/CAT6); ordinary Ethernet cables are only designed for indoor use and may deteriorate quickly when exposed to outdoor elements.
Hardware Manual Using the Bundled Conduit Gland The camera and the pre-installed network cable are resistant to salt water, weak acid, alcohol, oil, grease and other common solvents. However, in areas with fierce weather conditions and those that can easily be flooded, ensure that the exposed length of cable is also protected. It is recommended to use a flexible conduit with 1/2” diameter and the conduit gland (included in the package) to protect the camera cabling.
Hardware Manual Step 1: Remove the Pre-installed Network Cable (“Pigtail”) 1. Loosen the three (3) screws to detach the back cover. NOTE: A cable is connected inside the camera; do not abruptly pull the back cover. 2. Disconnect the network connector. 3. Remove the pre-installed cable gland and network cable using a wrench (not included in the package). 17 www.acti.
Hardware Manual Step 2: Prepare the Conduit Gland and Flex Conduit 1. Disassemble the bundled conduit gland as shown below. Body Clamping Nut Sealing Insert Lock Nut 2. Pull the Ethernet cable through the flex conduit. 3. Insert the clamping nut through the flex conduit. 18 www.acti.
Hardware Manual 4. Insert the sealing insert and attach it at the end of the flex conduit. Step 3: Install the Ethernet Cable 1. Insert the body (A) to the back cover and secure it with the lock nut (B). (B) (A) 2. Insert the Ethernet cable through the back cover and then align the sealing insert to the gland body. 19 www.acti.
Hardware Manual 3. Secure the clamping nut to the body. NOTE: Make sure the clamping nut is tight to avoid possible water leak. Step 4: Connect the Ethernet Cable 1. Connect the Ethernet cable to the Ethernet port inside the camera. 2. When done, close the back cover by tightening the three (3) screws. NOTE: Make sure the rubber ring on the cover is secured and the screws are completely tightened to avoid possible water leak. 20 www.acti.
Hardware Manual Replacing the Pre-Installed Square-Shaped “Pigtail” The pre-installed network cable comes with an Ethernet port (female connector), or known as a “pigtail”. The length of the cable is around 14 ~ 35 cm (varies by model). The network cable and gland are resistant to salt water, weak acid, alcohol, oil, grease and common solvents. 14 cm In case the installation environment requires a change of this network cable, follow the step-by-step procedures in this section to do so.
Hardware Manual Step 1: Remove the Pre-installed Network Cable (“Pigtail”) 1. Loosen the three (3) screws to detach the back cover. NOTE: A cable is connected inside the camera; do not abruptly pull the back cover. 2. Disconnect the network connector (A) and remove the sealing nut (B). (A) (B) 3. Pull out the network cable from the back cover and disassemble the parts as marked below. Seal Claw Sealing Nut 4.
Hardware Manual Step 2: Install the New Ethernet Cable 1. Insert the new Ethernet cable through the sealing nut, claw, seal, and cable gland of the back cover. 2. Attach the RJ-45 connector to the Ethernet cable. See How to Make an Ethernet Cable on page 36 for more information. 3. Assemble the seal and claw, and then connect the RJ-45 connector to the Ethernet port inside the camera. 2 2 1 2 4. Attach the back cover by tightening the three (3) screws.
Hardware Manual 5. Tighten the sealing nut. Make sure the rubber is tightly squeezed to avoid possible water leak. Rubber must be squeezed tightly NOTES on using Ethernet cables: When replacing the pre-installed network cable, it is recommended to use exterior-grade Ethernet cables (CAT5/CAT5e/CAT6); ordinary Ethernet cables are only designed for indoor use and may deteriorate quickly when exposed to outdoor elements. Exterior-grade Ethernet cables are waterproof and do not require a conduit. 24 www.
Hardware Manual Step 5: Connect the Cable Connect the other end of the network cable to a switch or injector. Then, connect the switch or injector to a network, PC, and a power source. See Power-over-Ethernet (PoE) connection example below. Network Ethernet Cable Ethernet Cable (Data) PoE Injector Power Cable Ethernet Cable (Data + Power) AC Power Source Camera Step 6: Access the Camera Live View See Accessing the Camera on page 30 for more information on how to access the Live View of the camera.
Hardware Manual Other Adjustments and Accessories This section describes the procedures on installing a memory card and resetting the camera. How to Install / Remove the Memory Card The camera supports local video recording or saving of snapshots to a memory card. NOTE: Supports microSDHC and microSDXC cards. How to Insert the Memory Card 4. Loosen the three (3) screws to detach the back cover. NOTE: A cable is connected inside the camera; do not abruptly pull the back cover. 5.
Hardware Manual 6. When done, ensure the rubber seal is aligned and attached to the back cover and then close the back cover by tightening the three (3) screws. CAUTION: Make sure the rubber seal is properly attached and the back cover is closed to ensure water or dust cannot enter the camera. How to Remove the Memory Card In case there is a need to remove the card, make sure to access the camera Web Configurator to safely “unmount” the card first (see the camera Firmware manual for more information).
Hardware Manual How to Reset the Camera In case there is a need to reset the camera to its default factory settings, do the following procedures while the camera is powered on. 5. Loosen the three (3) screws securing the back cover. NOTE: A cable is connected inside the camera; do not abruptly pull the back cover. 6. Using a pointed object, such as the tip of a pen, press and hold the Reset button for at least 5 seconds or until the Power LED lights up, to reset the camera. 7.
Hardware Manual How to Adjust the Viewing Angle (Not available in E37) 1. Open the front cover. 2. Attach the lens focus tuner to the lens. 3. Adjust the focus of the target area, based on the live view of the camera (see Access the Camera on page 34). 4. When done, close the front cover. CAUTION: The front cover must be tightly closed to ensure water or dust does not go through any opening. 29 www.acti.
Hardware Manual Accessing the Camera Configure the IP Addresses In order to be able to communicate with the camera from your PC, both the camera and the PC have to be within the same network segment. In most cases, it means that they both should have very similar IP addresses, where only the last number of the IP address is different from each other. There are 2 different approaches to IP Address management in Local Area Networks – by DHCP Server or Manually.
Hardware Manual By double-clicking with the left mouse on the camera model, it is possible to automatically launch the default browser of the PC with the IP address of the target camera filled in the address bar of the browser already. If you work with our cameras regularly, then there is even a better way to discover the cameras in the network – by using IP Utility.
Hardware Manual Using the Default Camera IP Address If there is no DHCP server in the given network, the user may have to assign the IP addresses to both PC and camera manually to make sure they are in the same network segment. When the camera is plugged into network and it does not detect any DHCP services, it will automatically assign itself a default IP: 192.168.0.100 Whereas the default port number would be 80.
Hardware Manual Manually adjust the IP addresses of multiple cameras: If there are more than one camera to be used in the same local area network and there is no DHCP server to assign unique IP addresses to each of them, all of the cameras would then have the initial IP address of 192.168.0.100, which is not a proper situation for network devices – all the IP addresses have to be different from each other.
Hardware Manual Access the Camera Now that the camera and the PC are both having their unique IP addresses and are under the same network segment, it is possible to use the Web browser of the PC to access the camera. You can use any of the browsers to access the camera, however, the full functionality is provided only for Microsoft Internet Explorer.
Hardware Manual The following examples in this manual are based on Internet Explorer browser in order to cover all functions of the camera. Assuming that the camera’s IP address is 192.168.0.100, you can access it by opening the Web browser and typing the following address into Web browser’s address bar: http://192.168.0.100 Upon successful connection to the camera, the user interface called Web Configurator would appear together with the login page.
Hardware Manual Appendix How to Make an Ethernet Cable 1. Prepare the following tools: Ethernet cable without connectors RJ-45 Connector (x2) RJ45 Crimping Tool Scissors 2. Cut about 1 inch into the plastic sheath from the end of the cable. 1 inch 3. Unwind the wires and arrange them according to the color sequence below. 1) 2) 3) 4) 5) 6) 7) 8) Stripe Orange Orange Stripe Green Blue Stripe Blue Green Stripe Brown Brown 4. Pinch the wires between your fingers and straighten them out.
