REV TEST SPECIFICATION PROCEDURE SPECIFICATION
LTR NO. OPR LIMITS C TEST DESCRIPTION SWITCH POS C WORK STEPS MFG LIMITS
AW/CRITICAL NOTATION
SUPPLEMENTS
91
SECURITY NOTATION PAGE
15101-000 (REV 970213 BCAS ASF5900/ENG_SPEC.DOT) (REV 07/18/2000 -OFC97-DATA SERVICES) HONEYWELL INTERNATIONAL INC.
ENGINEERING
SPECIFICATION
26 REPLY PULSE
CHARACTERISTICS
REPLY PULSE
CHARACTERISTICS
Perform test setup in
accordance with tables 1
and 5.
Perform test setup in
accordance with tables 1
and 5.
Interrogate the UUT with
an ATCRBS Mode A
interrogation at the
standard rate and power.
ATC-1400A
PRF: 0450
XPDR MDE A
On the ATC-1400A, set
the PRF thumbwheels to
0450 Hz and the XPDR
MODE knob to A.
S-1403
FUNC 1
On the S-1403, enter
FUNC 1.
Using an oscilloscope with
50-ohm impedance, look
at the XMTR output of the
ATC-1400A.
26.1 Rise:
<0.1 µs
Fall:
<0.2 µs
Measure and record the
10% to 90% rise and fall
times of the first framing
pulse, F1. The
measurements shall be as
specified.
Measure and record the
10% to 90% rise and fall
times of the first framing
pulse, F1. The
measurements shall be as
specified.
Rise:
<0.1 µs
Fall:
<0.2 µs
26.2 450 ± 100 ns Measure and record the
50-50% pulse width of the
first framing pulse, F1.
The measurement shall
be as specified.
Measure and record the
50-50% pulse width of the
first framing pulse, F1.
The measurement shall
be as specified.
450 ± 80 ns
26.3 20.3 ±
1 µs
Measure and record the
spacing between the two
framing pulses, F1 and
F2. The measurements
shall be as specified.
Measure and record the
spacing between the two
framing pulses, F1 and
F2. The measurements
shall be as specified.
20.3 ±
1 µs
