SECURITY NOTATION SPEC

NO.

IT4061400-907

SEE PAGE INDEX

FOR THIS SHEET

REV LETTER

CAGE

CODE

58960

REV LTR

SEE THE TITLE PAGE FOR PROPRIETARY AND DATA RIGHTS NOTATIONS.

REV

LTR

AW/CRITICAL NOTATION

SUPPLEMENTS

SECURITY NOTATION PAGE

15101-000 (REV 970213 BCAS ASF5900/ENG_SPEC.DOT) (REV 07/18/2000 -OFC97-DATA SERVICES) HONEYWELL INTERNATIONAL INC.

ENGINEERING

SPECIFICATION

3.3 Notes on operating the HP 64000 emulation system are as follows:

3.3.1 All tests requiring the HP 64000 emulation system shall be performed while executing the

SDP-185 monitor software. In the engineering environment, the monitor is invoked by executing

the 'HW' command file from within the MODESP user ID of the HP 64000 system.

3.3.2 All address and data information should be entered in Hex with a leading 0 and trailing H (the H

indicates the data is in hexadecimal). See example in 3.3.3.

3.3.3 Most emulation commands are invoked by pressing HP 64000 softkeys, found directly below the

CRT. Only hexadecimal addresses and data are typed using the standard typewriter keypad of

the HP 64000. For example, to change the contents of location C000 (Hex) to the value AAAA

(Hex), the following HP 64000 command would be entered:

modify memory 0C000H to 0AAAAH

In this example, the words (modify, memory, and to) are entered with single-keystroke

softkeys.

3.4 Notes on operation of the PC emulation system are as follows:

3.4.1 All tests requiring the PC emulation system shall be performed while executing the SDP-185

monitor software. In the engineering environment, the monitor is invoked by executing the 'SCP

MDS' command file.

3.4.2 All address and data information should be entered in Hex with a leading 0/ # for CACHE locations

and a leading 1# for local memory. See example in 3.4.3.

3.4.3 Most emulation commands are invoked by pressing the softkeys. Only addresses, data, and

'MDS' are typed using the standard typewriter keys. For example, to change the contents of

location C000 (Hex) to the value AAAA (Hex), the following PC command would be entered:

modify memory MDS word 0/#C0/0/0/ to AAAA

In this example, the words (modify, memory, word, and to) are entered with single-keystroke

softkeys.

3.5 When testing diversity, the two antenna signals are referred to as ANT A and ANT B. This

conversion is consistent with that used by the IFR transponder test equipment and does not need to

be correlated to the actual top and bottom antenna signals. In other words, the TOP ANT cable can

be connected to either ANT A port or ANT B port of the IFR equipment.
