User Instructions

SECURITY NOTATION SPEC

NO.

IT4061400-907

SEE PAGE INDEX

FOR THIS SHEET

REV LETTER

CAGE

CODE

58960

REV LTR

SEE THE TITLE PAGE FOR PROPRIETARY AND DATA RIGHTS NOTATIONS.

REV

LTR

AW/CRITICAL NOTATION

SUPPLEMENTS

SECURITY NOTATION PAGE

15101-000 (REV 970213 BCAS ASF5900/ENG_SPEC.DOT) (REV 07/18/2000 -OFC97-DATA SERVICES) HONEYWELL INTERNATIONAL INC.

ENGINEERING

SPECIFICATION

Table 4. Initial Setup For Internal RF Self-Test

Address Modify to

C000H thru C006H 0000H

C007H thru C00DH 5555H

C00EH D457H

C00FH AAAAH

C01FH FFFFH

C020H AAAAH

C021H AAAAH

C022H 5555H

C023H 5555H

C024H 000DH

C025H 009EH

C026H 00BFH

C028H 002AH

C02AH 5500H

C02BH FFAAH

C02FH 0007H

NOTE 1: Read 1DW4 (location 0D604).

NOTE 2: Copy bits 0 thru 3 of 1DW4 into bits 4 thru 7 and write the value 7H into bits 0 thru 3 of RF

0DW15 (location 0C027).

NOTE 3: Copy bits 4 thru 7 of 1DW4 plus 01DH into bits 0 thru 5 of RF 0DW17(location 0C029).
