Table 2. Initial Mode S Transponder (UUT) Configuration
(Mode S Interface Panel)
Signal Name
Switch
Position
Signal
Sense
UUT
Rear Connector
Pin No.
MODE S ADDRESS A1 0 OPEN J1B-1A
A2 1 GND J1B-1B
A3 0 OPEN J1B-1C
A4 1 GND J1B-1D
A5 0 OPEN J1B-1E
A6 1 GND J1B-1F
A7 0 OPEN J1B-1G
A8 1 GND J1B-1H
A9 0 OPEN J1B-1J
A10 1 GND J1B-1K
A11 0 OPEN J1B-2A
A12 1 GND J1B-2B
A13 0 OPEN J1B-2C
A14 1 GND J1B-2D
A15 0 OPEN J1B-2E
A16 1 GND J1B-2F
A17 0 OPEN J1B-2G
A18 1 GND J1B-2H
A19 0 OPEN J1B-2J
A20 1 GND J1B-2K
A21 0 OPEN J1B-3A
A22 1 GND J1B-3B
A23 0 OPEN J1B-3C
A24 1 GND J1B-3D
