1 Introduction to AR-R5800
AR-R5800 series is a 1U height, rack-mounted platform for networking appliance, e.g. VPN,
SSL, UTM or firewall. With Intel advanced Core 2 Quad / Duo / Pentium / Celeron CPU,
AR-R5800 is a powerful platform to satisfy different applications. By eight
10/100/1000Mbps LANs, the AR-R5800 is sufficient for the small to middle size business
security solution.
AR-R5800 series can be equipped with 2 x HDD for RAID 0/1 redundancy. Customers
don’t need to worry about data lost due to HDD defected problem. With LCM module,
users can easily understand system status. BIOS, GPIO and Jumper can control LAN
bypass feature. It provides flexibility to access Internet by user setting. It also has
standard PCIe x 8 slot. Customers can purchase suitable add-on card to meet their
appliance.
Key features:
1. Support Intel Core 2 Quad or Core 2 Duo or Pentium or Celeron CPU
2. Intel G41 + ICH7R Chipset to support RAID 0/1 redundancy
3. DDRIII DIMM x 2, up to 4GB memory
4. Intel 82574L 10/100/1000Mbps x 6 + 82541PI 10/100/1000Mbps x 2
5. Two pairs LAN ports support bypass feature (LAN 1/2 + LAN 3/4)
6. LAN bypass can be controlled by BIOS, GPIO and Jumper
7. CF socket, 2.5” HDD x 2, SATA II interface x 2
8. Console, VGA (pinhead), USB 2.0 x 4 (2 x connectors, 2 x pin head)
9. Support boot from LAN, console redirection
10. Support standard PCIe x 8 slot for feature expansion
11. LCM module to provide user-friendly interface
12. Standard 1U rack mount size
1.1 Specifications
Item Description
System AR-R5800
CPU Board AR-B5800
System Dimensions 442.4x371.5x44(mm)
