Manual

Revision: 1.0
Option Choice Description
Reset Configuration
Data
Enabled
Disabled
Normally, you leave this field Disabled. Select Enabled to
reset Extended System Configuration Data (ESCD) when you
exit Setup. If you have installed a new add-on and the system
reconfiguration has caused such a serious conflict, then the
operating system cannot boot.
Resources
Controlled By
Auto(ESCD)
Manual
The Award Plug and Play BIOS has the capacity to
automatically configure all of the boot and Plug and Play
compatible devices. However, this capability means absolutely
nothing unless you are using a Plug and Play operating
system such as Windows 95. If you set this field to “manual,”
then you may choose specific resources by going into each of
the submenus.
IRQ Resources
N/A
When resources are controlled manually, assign a type to
each system interrupt, depending on the type of the device
that uses the interrupt
3.4 Peripherals Setup
This option controls the configuration of the board’s chipset. Control keys for this screen
are the same as for the previous screen.
39
