Manual

Revision: 1.0
LAN1
LAN1 RJ45 Connector
FP_USB1
Internal USB2, USB3 connector.
SYSFAN1
System FAN Connector.
LAN2
LAN2 RJ45 Connector
LCM1
Pin Header for LCM
JP1
For LAN1/LAN2 Bypass Function
Select.
LAN3
LAN3 RJ45 Connector
GP1
GPIO Header.
RTC1
CR2032 Battery Hold Connector.
LAN4
LAN4 RJ45 Connector.
CF1
CF CARD SOCKET.
CCMOS1
CMOS Memory Clearing Header
LAN5
LAN5 RJ45 Connector
CPLD1
For CPLD Firmware Update
JP4
For LAN3/LAN4 Bypass Function
Select.
LAN6
LAN6 RJ45 Connector
ATXPWR1
ATX Power Supply input connector..
LAN7
LAN7 RJ45 Connector.
SATA2
SATA device connector #2.
LAN8
LAN8 RJ45 Connector.
SATA1
SATA device connector #1.
USB1
Two USB ports (USB0, USB1)
connector.
VGA1
VGA connecter (2x5 Pin Header)
COM1
RS232 Serial Port COM1.(RJ45)
ATX12V1
ATX12V Power Supply input
Connector.
LED1
4 in 1 LED for LAN Bypass, Power &
HDD LED.
SYSFAN3
System FAN Connector.
RST2
System Reset Switch.
CPUFAN1
CPU FAN Connector.
FP_USB2
Internal USB4, USB5 connector.
SYSFAN2
System FAN Connector.
