Operation Manual

English - 29 -
You can find detailed information for all menu
items in “Analogue TV Menu System” section.
Common Interface
• Press the MENU button to display the main
menu and use the
or button to highlight
the
“Common Interface” line and press the
OK button:
Main Menu
Channel List
Installation
Configuration
Timers
Language
TV Setup
Common Interface
Some Digital Terrestrial channels operate on
a Pay Per View basis. These require a
subscription and a hardware decoder.
Obtain the Conditional Access Module (CAM)
and the viewing card by subscribing to a pay
channel company, then insert those to the TV
using the following procedure.
• Switch off the TV and unplug from the mains.
• Insert the CAM and then the viewing card to
the slot that is located in the terminal cover
at the left-hand side of the TV (from front
view).
• The CAM should be correctly inserted, it is
impossible to insert fully if reversed. The
CAM or the TV terminal may be damaged if
the CAM is forcefully inserted.
• Connect the TV to the mains supply, switch
on and then wait for few moments until the
card is activated.
• Some CAMs may require the following set
up. Please set the CAM by entering the IDTV
menu, Common Interface then pressing the
OK button. (CAM set up menu is not
displayed when it is not required.)
• To see the viewing contract information: enter
IDTV; press the
MENU button, then highlight
Common Interface and press the OK button.
• When no module is inserted, “
No Common
Interface module detected
” message
appears on the screen.
• Refer to the module instruction manual for
details of the settings.
