KD9617/KD9619 1U Rackmount LCD Keyboard Drawer User Manual KD9617/KD9619: 1U Rackmount 17/19” Monitor Keyboard Drawer 14628 Central Ave, Chino, CA 91710 tel:909.597.7588, fax:909.597.1939 © Copyright 2013 Acnodes, Inc. All rights reserved. Product description and product specifications are subject to change without notice. For latest product information, please visit Acnodes’ web site at www.acnodes.com.
KD9617/KD9619 1U Rackmount LCD Keyboard Drawer Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment. Safety Instructions Please read all of these instructions carefully before you use the device.
KD9617/KD9619 1U Rackmount LCD Keyboard Drawer Contents < Part. 1 > KD9617 / KD9619 1.1 1.2 1.3 1.4 Package Content Structure Diagram & Dimension Installation Connection P.1 P.1 - 2 P.3 P.4 < Part. 2 > Specifications / OSD 2.1 2.2 2.3 Product Specifications Keyboard / Mouse Specifications On-screen Display Operation ( OSD ) P.5 - 6 P.7 P.8 - 9 < Part. 3 > Options 3.1 3.2 3.
KD9617/KD9619 1U Rackmount LCD Keyboard Drawer Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content. Check and make sure they are included and in good condition.
< Part 1 > < 1.1 > Package Content KD 9617 or K D9619 uni t X 1 - 6ft Combo KVM c ab le X 1 - Pow er a dapter & Power cord X 1 - M6 screw, cage nut & c up washer X 8 The above package content is only for the single console models. It varies with options such as HDMI, DVI-D, AV, audio, touchscreen & DC power. < 1.
< 1.2 > Dimension Front View UNIT : mm Sid e View 1mm = 0.03937 inch Top View Product Dimension (W x D x H) Packing Dimension (W x D x H) Net Weight Gross Weight KD9617 series 441.6 x 700 x 44 mm 17.4 x 27.6 x 1.73" 595 x 910 x 140 mm 23.4 x 35.8 x 5.5” 12 k g 26 lb 16.5 kg 36 lb KD9619 series 441.6 x 700 x 44 mm 17.4 x 27.6 x 1.73" 595 x 910 x 140 mm 23.4 x 35.8 x 5.5” 13 k g 29 lb 17.5 kg 39 lb Model The weight is only for the single console models.
< 1.3 > Installation - How to install Installation Slides Step ¦ Insert the left and right rear mounting brackets into the LCD c onsole drawer. Step ¦ ¦ 1 2 Measure the depth of the front and rear mounting rails. Align each rear mounting bracket to a suitable length. Step 3 Complete the installation ¦ Fix the LCD console drawer into the rack . M6 screw, cage nut & cup washer x 8 are provided.
< 1.4 > Connection to PS/2 or USB Server LCD console drawer LCD console drawer KVM KVM Combo KVM cable PS/2 server Combo KVM cab le USB server < 1.4 > Connection to external KVM LCD console drawer LCD console drawer KVM Combo KVM cable PS/2 console KVM KVM Combo KVM cable USB console KVM Caution : The LCD console drawer is hot-pluggable, but components of connected devices, such as the servers and KVM switch, may not be hot-pluggable.
KD9617/KD9619 1U Rackmount LCD Keyboard Drawer < Part 2 > < 2.1 > Product Specifications LCD Panel KD 9617 Manufactur er Panel Size ( diagonal ) 17-inch TFT color LCD 19-inch TFT color LCD 1280 x 1024 1280 x 1024 250 250 Contras t Ratio ( typ. ) 1000:1 1000:1 Color 16.7 M 16.7 M 80/80/80/80 80/80/80/80 5 5 0.264 0.294 337.92H x 270.33V 376.32H x 301.05V Display pix el ( dots x lines ) Brightness ( typ.
KD9617/KD9619 1U Rackmount LCD Keyboard Drawer Power Power Supply Range Auto-sensing 100 to 240VAC, 50 / 60Hz Power Consum ption Screen display ON 25W or less Power s aving m ode 4W or less Power button OFF 1W or less Regulatory Safety Approval FCC & CE Environmental Conditions Operating Tem peratur e Humidity 0 to 50°C degree 20~90%, non-condensing Storage Tem peratur e -5 to 60°C degree Humidity 5~90%, non-condensing Shock 10G acceleration (11ms duration) Vibration 5~500Hz 1G RM
< 2.2 > Keyboard / Mouse Specifications t Compact keyboard integrated with touchpad d Compact keyboard integrated with trackball Key force 90 ± 7g Travelling distance 4.
KD9617/KD9619 1U Rackmount LCD Keyboard Drawer < 2.3 > On-screen Display Operation ( OSD ) M embrane Switch Funct ion Turn the monitor on or off Display the OSD menu Act as an Enter key to select screen setting options Scroll through menu options and adjust the displayed co ntrol Exit t he OSD screen Go back to the previous on-screen sub-men u o r main menu Remark : All LED touch buttons in WHITE light. The LED of Power tou ch button will flash continuously when there is no signal input.
KD9617/KD9619 1U Rackmount LCD Keyboard Drawer < 2.
KD9617/KD9619 1U Rackmount LCD Keyboard Drawer < Part 3 > < 3.1 > Options : - HDMI - DVI-D - AV - Audio ( HDMI 1.1, C EA-861-D ) ( DVI-D TMD S s ingle link ) ( S-Vid eo + Compo site, BN C ) ( 3.5mm audio jack s for au dio in & o ut, and 2W + 2W spea kers ) For AV2.2 upgrade, either HDMI or DVI-D is provided. HDMI Audio S-Video BNC DVI-D Power KVM in - in - out PC Video 14628 Central Ave, Chino, CA 91710 tel:909.597.7588, fax:909.597.1939 © Copyright 2013 Acnodes, Inc. All rights reserved.
< 3.2 > Options : Touchscreen & driver 17” / 19" U SB Touchscreen Speci fication 17’ M odel 19” TRB 17” e-Resistive TCB 19” e-Capacitive Technology 5-W ire Resistiv e Capacitive Touch Point Single Single Stylus or Finger Finger = 50g / Stylus=R0.8 = 50g 35 million touches 300 million touches 15 ms 20 ms 80% ± 3% 93% ±2% 3H 9H 8% ± 3% 7% M ethod Activation Force Durability Response Time Optical Transmittance Surface Hardness Haze Glass 1.4 ±0.
KD9617/KD9619 1U Rackmount LCD Keyboard Drawer < 3.3 > Options : DC Power Model 12V 24V 48V Input rating Inp ut voltage: 1 2-Volt 24-Volt 48-Volt Inp ut range: 9 ~ 18V 18 ~ 36V 36 ~ 75V - No load 50 mA 50 mA 5 0 mA - Full load 4950 mA 2450 mA 1220 mA Output voltage: 1 2-Volt 12-Volt 12-Volt Output current : 4.16A 4.16A 4.
