Chapter 2 • Testing, Troubleshooting, and Maintenance
• 24 Hr Acq Log
If there is a problem, the applicable error code is displayed. For RF
communication, and HHTR-LP or user error codes, refer to HHTR-LP
Displayed Error Codes.
Configuration/Installation Status
You can view additional information about configuration and link status by
selecting Com Stat from the ORION Menu screen. Although this
information is read from the EMTR-2, check the RF Link Data: Acq Log
(refer to step 16. of this procedure) to verify recent successful ORION/EMTR
communication.
Complete the following steps to view configuration and link status data.
1. Press the On/Off button on the HHTR-LP. The “flash” screen appears
momentarily displaying the software version number. Firmware
Vn.n
is replaced with the firmware version number installed in your
HHTR-LP.
The Main Menu screen appears.
2. Press the down arrow once to position the arrow cursor in front of the
REMOTE option.
3. Press the Enter button.
4. Press the Enter button to accept the ORION default selection.
DCSI: HHTR-LP
Y72160-301
Www.twacs.com
Firmware Vn.n
Main Menu
Order
Serial Com
REMOTE
EMTR
TWACS
HHTR Config
Main Menu
Order
Serial Com
REMOTE
EMTR
TWACS
HHTR Config
Remote Menu
Select:
ORION
