ORION and EMTR-2 Communication Setup

This section describes the steps required to use the HHTR-LP to configure,

link, and remove/replace an ORION or EMTR-2.

RF equipment setup procedures consist of configuring the EMTR-2 and

making the RF communication link between the ORION and EMTR-2.

You may also view the communication statistics (Refer to

Field Troubleshooting on page 28), or test the link between the ORION and

EMTR-2 by reading the Total Consumption register for the applicable port

and verifying the reading on the auxiliary meter dials.

Install the ORION (Linking the ORION and EMTR-2)

Complete the following steps to link the ORION to a nearby EMTR-2.

1. Press the On/Off button on the HHTR-LP. The “flash” screen

appears momentarily displaying the software version number.

Firmware Vn.n is replaced with the firmware version number

installed in your HHTR-LP.

The Main Menu screen appears.

2. Press the down arrow once to position the arrow cursor in front of

the REMOTE option.

3. Press the Enter button.

4. Press the Enter button to accept the default selection.

DCSI: HHTR-LP

Y72160-301

Www.twacs.com

Firmware Vn.n

Main Menu

Order

Serial Com

REMOTE

EMTR

TWACS

HHTR Config
