Product Manual

4
MODEL 2-PS HD PORTABLE SODA BLASTER
ESTIMATED CFM REQUIREMENTS
PSI
90 13 19 29 +36 +50
80 12 18 27 34 +45
60 10 15 23 30 35
40 7 10 18 23 32
3/32” 1/8” 5/32” 3/16” ¼”
ESTIMATED MEDIA USAGE (LBS / MINUTE)
PSI 1/8” RESTRICTOR
90 .51 .92 1.47 2.21 4.04
80 .46 .88 1.38 1.70 3.25
60 .37 .78 1.20 1.57 2.62
40 .28 .55 .97 1.34 2.52
3/32” 1/8” 5/32” 3/16” ¼”
PSI 7/64” RESTRICTOR
90 .32 .58 .93 1.39 2.98
80 .29 .55 .92 1.33 2.40
60 .27 .53 .90 1.26 1.94
40 .26 .50 .88 1.21 1.86
3/32” 1/8” 5/32” 3/16” ¼”
PSI 3/32” RESTRICTOR
90 .29 .53 .84 1.26 2.24
80 .26 .50 .82 1.21 1.80
60 .25 .47 .80 1.12 1.45
40 .23 .45 .79 1.09 1.25
3/32” 1/8” 5/32” 3/16” ¼”
NOTES:
 FIGURES USED ARE BASED ON OUR TEST DATA. ACTUAL RESULTS
WILL VARY.
 CFM REQUIREMENTS BASED ON “DELIVERED CFM” TO UNIT.
 LBS / MINUTES MEDIA USAGE BASED ON MAINTENANCE GRADE SODA
SPRAYED INTO FREE AIR.
 ½” ID AIR SUPPLY LINE USED.
ACE SODA BLASTER
