Specifications

SETUP / BATTERIES / TRANSPORT (CONTINUED)
Preparing a 498KL Scale for Transport
This scale can be easily placed into carrying case (# 64771) for storage, or transport from one
room to another. This scale does not include the carrying case item # 64771, and must be
acquired separately (see Figure 6). To prepare the scale for transport, follow these steps:
1. Remove the display assembly and display bracket from its current position.
2. Unplug the AC adapter and USB cable from the scale platform, and remove the AC adapter
from the outlet.
3. Carefully store the AC adapter, display bracket, and display assembly in carrying case to
prevent damage during transport (see Figure 7).
4. With the scale platform on the floor, lift scale platform carefully and place scale platform into
the carrying case. Position scale platform such that the adaptor jack and USB port are facing
up (see Figure 7).
5. Close carrying case flap over the scale (see Figure 6).
6. Grasp the carrying case strap and lift carefully into the upright position. Position the strap
over a shoulder (see Figure 8). The scale can now be transported.
Required Parts
(1) Display assembly
(1) Scale platform
(1) Display bracket
(1) Carrying case (# 64771)
Note:
Carrying case item # 64771 is not included.
Figure 6
14
