SETUP / BATTERIES / TRANSPORT (CONTINUED)
Preparing the 498KL Scale for Use
Optional AC Adapter
1. Remove the protective plastic film covering the display (the film says “FACTORY
CALIBRATED”).
2. Connect the optional AC adapter into the adaptor jack on the scale platform (see Figure 2).
Warning
: To avoid a safety hazard, use AC adapter model ADPT30 (International, plug kit)
or ADPT31 (Domestic, USA).
3. Plug the scale’s AC adapter into the power source.
4. Ensure all objects are removed from the scale’s assembly. Press the ON/OFF button to turn
the scale on. The display will show “Start”, then “0.0” LB or “0.0” KG. Press the LB/KG button to
select the weight mode (LB or KG).
Note
: This scale will always default to the settings and units last used (LB or KG).
5. When the AC adapter is disconnected from the scale, the scale will switch to battery power if
batteries are installed.
Note
: If the set up procedure failed, refer to the troubleshooting instructions. If the problem is
not corrected, refer to qualified service personnel.
