Specifications

SETUP / BATTERIES / TRANSPORT
Preparing the 498KL Scale for Use
Replacing / Inserting Batteries
1. Remove the protective plastic film covering the display (the film says “FACTORY
CALIBRATED”).
2. Unplug the optional AC adapter, if connected to a power source.
3. Use a Phillips head screwdriver to remove the battery cover on the side of the display
assembly by unscrewing the (2) battery cover screws (see Figure 5).
4. Replace or install the batteries with new units. Health o meter recommends using an alkaline
or lithium battery, rated for 130°F (54°C) operation. Do not use zinc-carbon batteries.
5. Re-attach the battery cover to the display assembly.
6. Ensure all objects are removed from the scale’s assembly, and then press the ON/OFF
button to turn the scale on. The display will show “Start”, then “0.0” LB or “0.0” KG. Press the
LB/KG button to select the weight mode (LB or KG).
Note
: This scale will always default to the settings and units last used (LB or KG).
Note
: If the set up procedure failed, refer to the troubleshooting instructions. If the problem is
not corrected, refer to qualified service personnel.
Warning
: If the scale will not be used for some time, remove the batteries to avoid a
safety hazard. Disposal of batteries must be performed in accordance with the prevailing
national, regional or local regulations which apply to you.
Figure 5
12
