User`s manual
English-13English-12
LEVEL Description Minimum # of Drive
RAID 0 Block Level Striping (Drives are Added) 2
RAID 1 Mirroring 2
Table 2. RAID Modes
Figure 16. Completed Denition of RAID
RAID Setup Step 4:
Press <CTRL><Y> to save the RAID then press <CTRL><Y> again to conrm
(See Figure). Then enter the name of the RAID Volume, in this example
“MultiportRaid” (See Figure). After entering the name of the volume press
the <ENTER> then <CTRL><Y> to save and then the Space bar to use all
available space on the volume. Then press the <Y> key to reboot.
Figure 17. RAID Erase Warning
