RS-232 communication
MPC-684 has two RS-232 communication ports for interfacing to external devices.
You can control the ports by using commands.
One of the ports supports interfacing with the GP touch-panel (Digital corporation).
You can add more communication ports by using the MRS-402 board (max 4ch.)
Command for communication
CNFG#n channel n initialize
PRINT#n channel n transmit
INPUT#n channel n receive
CNFG#0 "9600b8pns1XON" /* 9600bps 8bit parity-none 1stop XON/OFF
INPUT#0 a$ /* string receive
b$="&H"+a$ /* string processing
v=VAL(b$) /* conversion string to variable
PRINT "&H"+a$ "=" v /* display to monitor screen ( the FTMW )
PRINT#0 HEX$(v)+"\n" /* transmit
