Rear Panel
Reset
Keep on pressing the Reset button more than 3 seconds, the
Wireless Portable Router will set all setting back to factory
default values.
WPS
To enable the WPS function via web configuration (Wireless
Settings> WPS), then press the WPS button once on the
Wireless Portable Router, the GREEN LED will start to flash.
To make a connection with other WPS supported device
within 2 minutes.
WAN
Connect the ADSL or Cable Modem here with RJ45 cable. If
your modem came with a cable, use the supplied cable,
otherwise, use a standard LAN cable.
LAN
Use standard LAN cables (RJ45 connectors) to connect your
PCs to the port. If required, any port can be connected to
another hub. Any LAN port will automatically function as an
"Uplink" port when necessary.
DC 3.3V/1.5A
Connect the power supply adapter here.
