Item Description
Signal Displays the signal strength of the connection
between the Wireless Network Adapter and the
Access Point it connects to.
BBS ID A set of wireless stations is referred to as a Basic
Service Set (BSS). Computers in a BSS must be
configured with the same BSS ID.
Current Configuration
Pref. SSID It shows the current SSID setting of the
Wireless Network Adapter.
BSS Type Displays the type of Basic Service Set,
Access Point or Peer to Peer.
MAC Address It shows the MAC Address of this device.
4X State 4x technology provides increased throughput
in 802.11 Infrastructure and ad hoc networks.
The technology only has been implemented
in TI-Based WLAN devices
Tx Rate Shows the current transfer rate.
Signal Quality Displays the signal strength of the connection
between the Wireless Network Adapter and
the Access Point it connects.
BSSID the BSSID of the Access Point to which the
card is associated
B/G Mode It displays the card mode you are currently
using.( 802.11b, 802.11b+, and 802.11g)
Connect Highlight one of the device from the list area
and press the Connect button to access it.
Modify There will be three tabs for you to modify, see
the detailed information on page 21.
Rescan Searches for all available networks. Clicking
on the button, the device will start to rescan
and list all available sites.
