EHE
EHE N250k to N500k-TL
20�3 EHE N250k to N500k-TL
Easy Installation Termination Addressing Sensors RS485 Meters RS485 Interface
No Yes Yes
Yes Yes RS485
The following types are to be connected according to this diagram:
N250K, N250K-TL, N500K-TL
Overview
•
Integrated interface
•
Where to connect: Terminal strip inside the inverter
•
2-pin wiring
•
Communication address must be allocated.
•
Installation steps
• Switch off the inverters and Solar-Log™
• Connect inverters to the Solar-Log™
• Connect the inverters to each other
• Enter the communication address on the interver's display.
Every address may only be used once.
Address range 1 to 247.
Connect inverters to the Solar-Log™
The wiring is done using a
•
self-made cable connection with terminal block connector.
•
Where to connect: Terminal strip inside the inverter
Procedure
•
If you are making the cable yourself, connect the wires as shown in the following diagram:
Solar-Log™ terminal strip connector Terminal strip inside the inverter
Terminal Terminal
► 1 (Data+) JX9 - A
► 4 (Data-) JX9 - B
•
If only one inverter is to be connected, terminate it according to the manufacturer's specifica-
tions.
•
Insert the terminal block connector into the Solar-Log™ RS485 socket.
Connect the inverters to each other
•
Connect with a shielded twisted-pair cable.
•
Where to connect: Terminal strip inside the inverter
