Voltwerk
Voltwerk (only Solar-Log 1000 and 2000)
84 Voltwerk
84�1 Voltwerk (only Solar-Log 1000 and 2000)
Note
Voltwerk inverters can only be connected to the Solar-Log 1000 and 2000, as only this one
has a CAN interface.
The following description relates to inverters without transformers produced in or after 2007.
Easy Installation Termination Addressing Sensors RS485 Meters RS485 Interface
No
Yes
No
No No CAN bus
Overview
•
CAN only to be used on Solar-Log 1000 and 2000 (CAN interface).
•
Integrated interface
•
Where to connect: CAN socket on the outside of the bottom of the inverter.
•
Only use ready-made cable sets.
Two different special cable sets must be ordered separately.
- Prefabricated cable set between the Solar-Log 1000 and 2000 and the first inverter, includ-
ing cable termination.
- Ready-made cable set with 5 pin Phoenix contact connection plug for connecting the invert-
ers to each other.
The number of cables are required depends on the number of inverters.
Maximum total cable length: 200 m
•
Communication address does not have to be assigned
•
Installation steps
• Switch off the inverters and Solar-Log™
• Connect inverters to the Solar-Log™
• Connect the inverters to each other
Connect the inverters to the Solar-Log 1000 and 2000�
Connection is only done using a ready-made data cable, specially for connecting to the Solar-Log
1000 and 2000 (optional extra; not supplied).
Procedure
1. Insert the CAN plug into the inverter CAN IN socket.
2. If only one inverter is to be connected this must be terminated.
Insert the two 5 pin 120 Ω terminal resistors from the ready-made cable set into the CAN OUT
socket.
3. Insert the terminal block connector into the Solar-Log 1000 and 2000 CAN socket.
