Installation manual

220
Sungrow
Sungrow
73 Sungrow
73�1 Sungrow
Easy Installation Termination Addressing Sensors RS485 Meters RS485 Interface
Yes 120 Ω resistor Yes
Yes Yes RS485
Overview
•
Integrated interface
•
Where to connect: RJ45 socket or COM round sockets on the outside of the inverter
•
2-pin wiring
•
Communication address must be allocated.
•
Installation steps
• Switch off the inverters and Solar-Log™
• Connect inverters to the Solar-Log™
• Connect the inverters to each other
• Allocate communication address
Note:
The inverter's communication connection is then changed to the from the round socket to
RJ45. Currently, the SG1,5KTL is still supplied with round sockets.
Connect inverters to the Solar-Log™
The wiring is done using a
•
self-made, shielded 2 wire data cable with round plug and terminal block connector.
Procedure
1. If you are making the cable yourself, connect the wires as shown in the following diagram:
Solar-Log™ terminal strip connector Round socket inverter for SG1,5KTL
Terminal PIN
► 1 ► 1 (A)
► 4 ► 2 (B)
