Installation manual

209
Solectria
Solectria >9k
Connect the inverters to each other
•
Connect with a shielded twisted-pair cable.
•
Where to connect: Terminal strip inside the inverter
Procedure
•
If you make the cable yourself, connect the wires as shown in the diagram:
Terminal strip inside the inverter Terminal strip inside the inverter
PIN PIN
RS485 A RS485 A
RS485 G RS485 G
RS485 B RS485 B
•
Wire the remaining inverters to each other according to the manufacturer's specifications.
•
Terminate the last inverter according to the inverter instructions.
•
Insert the terminal block connector into the Solar-Log™ RS485 socket.
The RS485 connections on the terminal strip are each double connections so that the wiring can also
be continued to the next inverter.
Procedure
1. Connect the data cable to the free blocks A, B and G on inverter 1.
2. Connect the other end of the cable to the blocks A, B and G on inverter 2.
3. Connect the remaining inverters in the same way.
4. Terminate in the last inverter according to the manufacturer's instructions.
5. Close the inverter if no other inverters are to be connected.
Notes on inverter addresses
•
Recommendation: Continuous numbering starting with 1.
•
Settings: On the inverter operating display.
•
Procedure: Follow the manufacturer's documentation for the inverter.
