SolaX Power
SolaX Power X1
69 SolaX Power
69�1 SolaX Power X1
Easy Installation Termination Addressing Sensors RS485 Meters RS485 Interface
No Yes Automatic
No No RS422
Thefollowingtypesaretobeconnectedaccordingtothisdiagram:
SL-TL1500, SL-TL2200, SL-TL2500, SL-TL2800, SL-TL3000, SL-TL3300T, SL-TL3600T, SL-TL4400T,
SL-TL5000T
Select SolaXPower X1 during the inverter detection.
Overview
•
Integrated interface.
•
2 RJ45 sockets on the outside of the inverter.
•
4-pin wiring.
•
Communication address does not have to be assigned
•
Installation steps
• Switch off the inverters and Solar-Log™.
• Connect inverters to the Solar-Log™.
• Connect the inverters to each other
Note
Only connect inverter using the RS485/422 B or RS485/422 C interface.
Connect inverters to the Solar-Log™�
The wiring is done using a
•
self-made, shielded 8 wire data cable and terminal block connector.
•
Where to connect: RJ45 socket on the inverter
Caution
Risk of damage to the unit!
The Solar-Log™ also has an RJ45 socket, which must never be connected to the RJ45
socket on the inverter.
► OnlyconnectinvertersviatheRS485/422Solar-Log™interface(s).
