Installation manual

190
SMA
Connect SMA with original SMA RS485 piggy back and the SMARS485 data module
66�3 Connect SMA with original SMA RS485 piggy back and the SMARS485
data module
Easy Installation Termination Addressing Sensors RS485 Meters RS485 Interface
Yes
Resistor jumper
No
Yes Yes RS485
Overview
•
Interface not integrated; retrofit the SMA RS485 piggyback card
•
Where to connect: Terminal strip inside the inverter on the piggyback
•
Communication address does not have to be assigned
•
3-pin wiring
•
Installation steps
• Switch off the inverters and Solar-Log™
• Installing the original SMA RS485 piggyback in the inverter
• Connect inverters to the Solar-Log™
• Connect the inverters to each other
Installing the original SMA RS485 piggyback in the inverter
Procedure
► Install the original SMA RS485 piggy back in the inverter in accordance with the interface card
installation instructions.
Connect inverters to the Solar-Log™
The wiring is done using a
•
ready-made data cable (optional extra; not supplied)
or
•
self-made, shielded 3 wire data cable and terminal block connector.
Procedure
1. Open the inverter as shown in the inverter's instructions.
2. Pull the free wires through the wire opening in the inverter.
3. Pull the cable through the insulation tube.
Note
The wire must be enclosed in the insulating hose inside the inverter.
4. If you are making the cable yourself, connect the wires as shown in the following diagram:
Solar-Log™ terminal strip connector Inverter terminal strip
Terminal Terminal
► 1 ► 2
► 3 ► 5
► 4 ► 7
5. Groundtheconnection:Connectterminal5ontheinvertertotheinverterhousingusingthesup-
