Schneider Electric
Schneider Electric SunEzy
62 Schneider Electric
62�1 Schneider Electric SunEzy
Easy Installation Termination Addressing Sensors RS485 Meters RS485 Interface
No
Yes
No
No No RS422
Overview
•
Interface not integrated; Retrofit RS485 interface card.
•
4-pin cable – only on RS485/422 B connection of the Solar-Log™
•
Communication address does not have to be assigned
•
Multi-string technology
The inverters are fitted with 1 or 3 MPP trackers depending on the model. Each string input is moni-
tored separately and ideally adjusted to the connected modules.
The Solar-Log™ automatically detects how many inverters and strings are active during inverter de-
tection.
Note
The order in which the inverters are displayed in the Solar-Log™ after detection is random.
We strongly recommend that you change the order of the inverters immediately after de-
tection at startup in the Configuration|Device|Configuration|Order menu box.
The inverters can be identified using the displayed serial number.
•
Installation steps
• Switch off the inverters and Solar-Log™
• Install the RS485 interface in the inverter
• Connect inverters to the Solar-Log™
• Connect the inverters to each other
Installing the RS485 interface
Procedure
► Insert the RS485 interface in the bottom of the inverter in accordance with the interface card
installation instructions and screw in.
Connect inverters to the Solar-Log™
The wiring is done using a
•
ready-made BKL1 data cable (optional extra; not supplied)
or
•
self-made, shielded 4 wire data cable and terminal block connector.
