Kostal and Solar-Fabrik
Kostal Pico and Solar-Fabrik Inverter Convert T (RS485)
40 Kostal and Solar-Fabrik
40�1 Kostal Pico and Solar-Fabrik Inverter Convert T (RS485)
Easy Installation Termination Addressing Sensors RS485 Meters RS485 Interface
Yes
Yes
Yes
Yes Yes RS485
Overview
•
Integrated interface
•
Where to connect: Terminal strip inside the inverter
•
3-pin wiring
•
Communication address must be allocated.
•
Multi-string technology
Pico / Convert inverters are fitted with several MPP trackers: Each string input is monitored separately
and ideally adjusted to the connected modules.
Depending on any parallel connections inside the inverter the Solar-Log™ can read the data from up
to 3 individual strings.
During the inverter detection, the Solar-Log™ automatically detects how many MPP trackers are ac-
tive; only the active MPP trackers are displayed. The inverter must be feeding data in for successful
detection.
•
Installation steps
Switch off the inverters and Solar-Log™
Connect inverters to the Solar-Log™
Connect the inverters to each other
Allocate communication address
Connect inverters to the Solar-Log™
The wiring is done using a
•
ready-made data cable (optional extra; not supplied)
or
•
self-made, shielded 3 wire data cable and terminal block connector.
