© 2005 Microchip Technology Inc. DS21953A-page 9
MCP4821/MCP4822
Note: Unless otherwise indicated, T
A
= +25°C, V
DD
= 5V, AV
SS
= 0V, V
REF
= 2.048V, Gain = 2, R
L
= 5 kΩ, C
L
= 100 pF.
FIGURE 2-7: Full-Scale V
OUTA
w/G = 1
(V
REF
) vs. Ambient Temperature and V
DD
.
FIGURE 2-8: Full-Scale V
OUTA
w/G = 2
(2V
REF
) vs.Ambient Temperature and V
DD
.
FIGURE 2-9: Output Noise Voltage
Density (V
REF
Noise Density w/G = 1) vs.
Frequency.
FIGURE 2-10: Output Noise Voltage (V
REF
Noise Voltage w/G = 1) vs. Bandwidth.
2.040
2.041
2.042
2.043
2.044
2.045
2.046
2.047
2.048
2.049
2.050
-40 -20 0 20 40 60 80 100 120
Ambient Temperature (°C)
Full Scale V
OUT
(V)
V
DD
: 4V
V
DD
: 3V
V
DD
: 2.7V
4.076
4.080
4.084
4.088
4.092
4.096
4.100
-40 -20 0 20 40 60 80 100 120
Ambient Temperature (°C)
Full Scale V
OUT
(V)
V
DD
: 5.5V
V
DD
: 5V
1.E-07
1.E-06
1.E-05
1.E-04
1E-1 1E+0 1E+1 1E+2 1E+3 1E+4 1E+5
Frequency (Hz)
Output Noise Voltage Density
(μV/
Hz)
0.1 1 10 100 1k 10k 100k
100
10
1
0.1
1.E-05
1.E-04
1.E-03
1.E-02
1E+2 1E+3 1E+4 1E+5 1E+6
Bandwidth (Hz)
Output Noise Voltage (mV)
100 1k 10k 100k 1M
E
ni
(in V
RMS
)
10.0
1.00
0.10
0.01
E
ni
(in V
P-P
)
Maximum Measurement Time = 10s
