MCP4821/MCP4822
DNL (Note 1) DNL — ±0.25 — LSb Device is monotonic
Offset Error V
OS
— ±0.02 — % of FSR Code 0x000h
Offset Error Temperature
Coefficient
V
OS
/°C — -5 — ppm/°C +25°C to +125°C
Gain Error g
E
— -0.10 — % of FSR Code 0xFFFh, not including offset
error
Gain Error Temperature
Coefficient
ΔG/°C — -3 — ppm/°C
Internal Voltage Reference (V
REF
)
Nominal Reference Voltage V
REF
— 2.048 — V V
OUTA
when G = 1x and
Code = 0xFFFh
Temperature Coefficient
(Note 1)
ΔV
REF
/°C — 125 — ppm/°C -40°C to 0°C
— 0.25 — LSb/°C -40°C to 0°C
— 45 — ppm/°C 0°C to +85°C
— 0.09 — LSb/°C 0°C to +85°C
Output Noise (V
REF
Noise) E
NREF
(0.1 - 10 Hz)
— 290 — µV
p-p
Code = 0xFFFh, G = 1
Output Noise Density e
NREF
(1 kHz)
—1.2—µV/
√
Hz Code = 0xFFFh, G = 1
e
NREF
(10 kHz)
—1.0—µV/
√
Hz Code = 0xFFFh, G = 1
1/f Corner Frequency f
CORNER
— 400 — Hz
Output Amplifier
Output Swing V
OUT
— 0.010 to
V
DD
– 0.040
— Accuracy is better than 1 LSb for
V
OUT
= 10 mV to (V
DD
– 40 mV)
Phase Margin PM — 66 — °
Slew Rate SR — 0.55 — V/µs
Short Circuit Current I
SC
—17—mA
Settling Time t
SETTLING
— 4.5 — µs Within 1/2 LSb of final value from
1/4 to 3/4 full-scale range
Dynamic Performance
DAC-to-DAC Crosstalk — <10 — nV-s Note 2
Major Code Transition Glitch — 45 — nV-s 1 LSb change around major carry
(
0111...1111 to
1000...0000)
Digital Feedthrough — <10 — nV-s Note 2
Analog Crosstalk — <10 — nV-s Note 2
5V EXTENDED TEMPERATURE SPECIFICATIONS (CONTINUED)
Electrical Specifications: Unless otherwise indicated, V
DD
= 5V, AV
SS
= 0V, V
REF
= 2.048V, output buffer gain (G) = 2x,
R
L
= 5 kΩ to GND, C
L
= 100 pF. Typical values at +125°C by characterization or simulation.
Parameters Sym Min Typ Max Units Conditions
Note 1: By design, not production tested.
2: Too small to quantify.
