MCP4821/MCP4822
DS21953A-page 2 © 2005 Microchip Technology Inc.
1.0 ELECTRICAL
CHARACTERISTICS
Absolute Maximum Ratings †
V
DD
............................................................................................................. 6.5V
All inputs and outputs ...................AV
SS
– 0.3V to V
DD
+ 0.3V
Current at Input Pins ....................................................±2 mA
Current at Supply Pins ...............................................±50 mA
Current at Output Pins ...............................................±25 mA
Storage temperature .....................................-65°C to +150°C
Ambient temp. with power applied ................-55°C to +125°C
ESD protection on all pins ........... ≥ 4 kV (HBM), ≥ 400V (MM)
Maximum Junction Temperature (T
J
)..........................+150°C
† Notice: Stresses above those listed under “Maximum
Ratings” may cause permanent damage to the device. This is
a stress rating only and functional operation of the device at
those or any other conditions above those indicated in the
operational listings of this specification is not implied.
Exposure to maximum rating conditions for extended periods
may affect device reliability.
5V AC/DC CHARACTERISTICS
Electrical Specifications: Unless otherwise indicated, V
DD
= 5V, AV
SS
= 0V, V
REF
= 2.048V, output buffer gain (G) = 2x,
R
L
= 5 kΩ to GND, C
L
= 100 pF, T
A
= -40 to +85°C. Typical values at +25°C.
Parameters Sym Min Typ Max Units Conditions
Power Requirements
Input Voltage V
DD
2.7 — 5.5
Input Current - MCP4821
Input Current - MCP4822
I
DD
—
—
330
415
400
750
µA Digital inputs grounded, Output
unloaded, code = 0x000
Hardware Shutdown Current I
SHDN
—0.3 2 µA
Software Shutdown Current I
SHDN_SW
—3.3 6 µA
Power-on-Reset Threshold V
POR
—2.0 — V
DC Accuracy
Resolution n 12 — — Bits
INL Error INL -12 2 12 LSb
DNL
(Note 1) DNL -0.75 ±0.2 +0.75 LSb Device is monotonic
Offset Error V
OS
-1 ±0.02 1 % of FSR Code = 0x000h
Offset Error Temperature
Coefficient
V
OS
/°C — 0.16 — ppm/°C -45°C to 25°C
— -0.44 — ppm/°C +25°C to 85°C
Gain Error g
E
-2 -0.10 2 % of FSR Code 0xFFFh, not including offset
error
Gain Error Temperature
Coefficient
ΔG/°C — -3 — ppm/°C
Internal Voltage Reference (V
REF
)
Nominal Reference Voltage V
REF
2.008 2.048 2.088 V V
OUTA
when G = 1x and
Code = 0xFFFh
Temperature Coefficient
(Note 1)
ΔV
REF
/°C — 125 325 ppm/°C -40°C to 0°C
— 0.25 0.65 LSb/°C -40°C to 0°C
— 45 160 ppm/°C 0°C to +85°C
— 0.09 0.32 LSb/°C 0°C to +85°C
Output Noise (V
REF
Noise) E
NREF
(0.1-10 Hz)
— 290 — µV
p-p
Code = 0xFFFh, G = 1
Output Noise Density e
NREF
(1 kHz)
—1.2 —µV/
√
Hz Code = 0xFFFh, G = 1
e
NREF
(10 kHz)
—1.0 —µV/
√
Hz Code = 0xFFFh, G = 1
1/f Corner Frequency f
CORNER
— 400 — Hz
Note 1: By design, not production tested.
2: Too small to quantify.
