PC/104 CPU Module PFM-540I Rev.B
Appendix C Mating Connector C - 2
C.1 List of Mating Connectors and Cables
The table notes mating connectors and available cables.
Mating Connector
Connector
Label
Function
Vendor Model no
Available Cable AAEON Cable
P/N
CN1 Front
Panel
Connector
Neltron 2226A-XX N/A
CN2 PS2
Keyboard/
Mouse
Connector
Neltron 2026B--XX Keyboard & Mouse
Cable
1700060152
CN3 Option
Power
Connector
Dupont 2541-1H
N/A
CN4 USB
Connector
Neltron 2026B--XX USB Cable 1709100201
CN5 VGA
Display
Connector
Neltron 2026B--XX CRT Cable 1701160201
CN6 USB
Connector
Neltron 2026B--XX USB Cable 1709100201
CN8 LPT Port
Connector
Keentop 1014
Series
Parallel Port Cable 1701260201
CN9 IDE
Connector
Keentop 1014
Series
IDE Cable 1701440350
CN10 COM1
Connector
Keentop 1014
Series
Serial Port Cable 1701100207
CN11 COM3
Connector
Keentop 1014
Series
Serial Port Cable 1701100207
CN12 Power
Connector
Ever 2542H-04 N/A
CN13 COM2
Connector
Keentop 1014
Series
Serial Port Cable 1701100207
CN14 Ethernet
Connector
Keentop 1014
Series
Ethernet Cable 1700100200
CN15 LCD
Connector
HO TIEN 1255H N/A
