PC/104 CPU Module PFM-540I Rev.B
Chapter 2 Quick Installation Guide 2- 19
25
N.C 26 N.C
27
RED0 28 RED1
29
RED2 30 RED3
31
RED4 32 RED5
33
GND 34 GND
35
CLOCK 36 VSYNC
37
DE 38 HSYNC
39
N.C 40 ENAVEE
2.25 COM4 Connector (CN16)
Pin Signal Pin Signal
1 DCD 2 RXD
3 TXD 4 DTR
5 GND 6 DSR
7 RTS 8 CTS
9 RI 10 N.C
2.26 Battery Connector (BAT1)
Pin Signal Pin Signal
1 +3V 2
GND
2.27 DDR1 SODIMM Slot (SODIMM1 )
Standard SODIMM Slot
Note from AMD:
Memory configurations supported. Only one DIMM or SODIMM is
