PC/104 CPU Module PFM-540I Rev.B
Chapter 2 Quick Installation Guide 2 - 18
23
GREEN6 24 GREEN7
25
RED0 26 RED1
27
RED2 28 RED3
29
RED4 30 RED5
31
RED6 32 RED7
33
GND 34 GND
35
CLOCK 36 VSYNC
37
DE 38 HSYNC
39
N.C 40 ENAVEE
18-bit TTL
Pin Signal Pin Signal
1
+5V
2
+5V
3
GND
4
GND
5
+3.3V
6
+3.3V
7
ENBKL
8
GND
9
N.C 10 N.C
11
BLUE0 12 BLUE1
13
BLUE2 14 BLUE3
15
BLUE4 16 BLUE5
17
N.C 18 N.C
19
GREEN0 20 GREEN1
21
GREEN2 22 GREEN3
23
GREEN4 24 GREEN5
