PC/104 CPU Module PFM-540I Rev.B
Chapter 2 Quick Installation Guide 2 - 14
2.17 LPT Port Connector (CN8)
Pin Signal Pin Signal
1
#STROBE
2
#AFD
3
DATA0
4
#ERROR
5
DATA1
6
#INIT
7
DATA2
8
#SLIN
9
DATA3
10
GND
11
DATA4
12
GND
13
DATA5
14
GND
15
DATA6
16
GND
17
DATA7
18
GND
19
#ACK
20
GND
21
BUSY
22
GND
23
PE
24
GND
25
SELECT
26
N.C
2.18 IDE Connector (CN9)
Pin Signal Pin Signal
1
#RESET
2
GND
3
DATA7
4
DATA8
5
DATA6
6
DATA9
7
DATA5
8
DATA10
9
DATA4
10
DATA11
11
DATA3
12
DATA12
