PC/104 CPU Module PFM-540I Rev.B
Chapter 2 Quick Installation Guide 2- 11
2.10 Front Panel Connector (CN1)
Pin Signal
1 Power LED(+)
2 Power LED(-)
3 N.C
4 Speaker(+)
5 Speaker(-)
6 N.C
7 IDE LED(+)
8 IDE LED(-)
9 N.C
10 Reset(+)
11 Reset(-)
12 N.C
13 Lan Speed LED(+)
14 Lan Speed LED(-)
15 Lan Active LED(+)
16 Lan Active LED(-)
17 N.C
18 N.C
19 N.C
20 N.C
21 N.C
