PC/104 CPU Module PFM-540I Rev.B
Chapter 1 General Information 1- 4
1.3 Specifications
System
 Processor AMD Geode LX 800 (500MHz)
Processor
 System Memory 200-pin Onboard DDR SDRAM
SODIMM x 1, Max. 1GB for DDR333
and 512MB for DDR 400 (Please refer
to the Quick Installation Guide 2.27
DDR1 SODIMM Slot for details)
 Chipset AMD LX 800 + CS5536
 I/O Chipset SCH3114-NU (SMSC3114i-NU for
WiTAS series products)
 Ethernet Intel 82551ER, 10/100Mbps,
RJ-45 x 1 (Intel 82551IT for WiTAS
series products)
 BIOS Award 1MB Flash ROM
 PCI to ISA solution ITE 8888
 Watchdog Timer 255 levels
 RTC CS5536
 Hardware Monitor SMSC SCH3114
 Solid Storage Disk CompactFlash™ Type I x 1
 Expansion Interface PC/104 socket x 1
 Power Requirement +5V/AT
 Board Size 3.55”(L) x 3.775”(W) (90mm x 96mm)
