Compact Board PCM-5895 Rev.B
Chapter 2 Quick Installation Guide 2-27
29 NC 30 NC
2.33 Ethernet 10/100Base-TX Connector (CN26)
Pin Signal Pin Signal
1
RXD-
2
RXD+
3
NC (N GND)
4
NC (N GND)
5
GND
6
GND
7
NC (C GND)
8
NC (C GND)
9
TXD+
10
TXD-
2.34 LCD Inverter (CN27)
Pin Signal Pin Signal
1 12V/5V 4 GND
2 VCON 5 BKL_EN
3 GND
2.35 IrDA (CN29)
Pin Signal
1 +5V
2 NC
3 RX
4 GND
5 TX
