Compact Board PCM-5895 Rev.B
Chapter 2 Quick Installation Guide 2- 26
27
R0
28
R1
29
R2
30
R3
31
R4
32
R5
33
GND
34
GND
35
LCD_CLK
36
LCD_VS
37
LCD_DE
38
LCD_HS
39
NC
40
TP
2.32 LVDS (CN24)
Pin Signal Pin Signal
1 BKL_EN 2 NC
3 VLCD 4 GND
5 LVDS_CLK# 6 LVDS_CLK
7 VLCD 8 GND
9 TX0# 10 TX0
11 TX1# 12 TX1
13 TX2# 14 TX2
15 TX3# 16 TX3
17 NC 18 NC
19 NC 20 NC
21 NC 22 NC
23 NC 24 NC
25 NC 26 NC
27 VLCD 28 GND
