Owner manual

Compact Board PCM-5895 Rev.B
Chapter 2 Quick Installation Guide 2- 24
3
RXD+
4
NC (N GND)
5
NC (N GND)
6
RXD-
7
NC (C GND)
8
NC (C GND)
9
GND
10
GND
2.30 LAN LED (CN13, CN25)
Pin Signal Pin Signal
1
RX
2
+3.3V
3
LINK10/100
4
+3.3V
5
TX
6
+3.3V
2.31 TFT LCD (CN23)
For 24-bit TFT LCD
Pin Signal Pin Signal
1
+5VLCD
2
+5VLCD
3
GND
4
GND
5
+3.3VLCD
6
+3.3VLCD
7
BKL_EN
8
GND
9
B0
10
B1
11
B2
12
B3
13
B4
14
B5
15
B6
16
B7
17
G0
18
G1
19
G2
20
G3
21
G4
22
G5
