Compact Board PCM-5895 Rev.B
Chapter 2 Quick Installation Guide 2- 18
9 5VSB 19 +5V
10 +12V 20 +5V
2.21 AT Power Socket (CN11)
Pin Signal
1 NC
2 +5V
3 +12V
4 -12V
5 GND
6 GND
7 GND
8 GND
9 -5V
10 +5V
11 +5V
12 +5V
2.22 IDE Hard Drive (CN12)
Pin Signal Pin Signal
1
RESET#
2
GND
3
D7
4
D8
5
D6
6
D9
7
D5
8
D10
